Air cap types:

• Trans-tech HVLP (TE10, TE20) – high-pressure air cap – suitable for clearcoats, acrylic paints as well as base coats (water- and solventbased)

• HVLP (HV30) – Low pressure air cap – suitable for basecoats only

Air consumption for each air cap:

• TE10 (Trans-Tech): 270 L / min. (9.5 cfm) at 2 bar

• TE20 (Trans-Tech): 360 L / min. (12.7 cfm) at 2 bar

• HV40 (HVLP): 460 L / min. (16.2 cfm) at 2 bar

Technical Specifications::

• Air inlet thread: 1/4″ male thread

• Flow cup: 560 ml

• Weight (with gravity cup): 778 gr

• Gun body: Anodized aluminum

• Air cap: brass, nickel-plated

• Air cap retaining ring: Anodized aluminum

• Fluid tip, fluid needle: Stainless Steel

• Spray head: aluminum, hard anodized
